Introduction

The conical fermentation tank is also called “straw hat tank” or “trapezoidal tank”. It can reduce oxidation and increase the immersion strength during the fermentation process. The large manhole can be customized according to user requirements and the mechanical cap can be used.

Configuration

Automatic temperature control
Cooling jacket
Heating jacket
Maitreya board

send us email

Leave a Message

wahtsapp

Product Parameters

Product Model	Capacity	Capacity (L)	Dimensions (mm)	Plate Thickness	Material
WZC-1	1m³	1000	1100*2200	2	304
WZC-2	1.5m³	1500	1300*2200	2	304
WZC-3	2m³	2000	1200*3000	2	304
WZC-4	3m³	3000	1500*3100	2	304
WZC-5	5m³	5000	1600*3700	2	304
WZC-6	6m³	6000	1770*3700	2	304
WZC-7	7.5m³	7500	2000*3700	2.5	304
WZC-8	8m³	8000	2050*3700	2.5	304
WZC-9	10m³	10000	2100*4400	2.5	304
WZC-10	12.5m³	12500	2100*4900	2.5	304
WZC-11	15m³	15000	2300*4900	2.5	304
WZC-12	20m³	20000	2450*5510	2.5	304
WZC-13	30m³	30000	2800*4880	2.5	304

Performance and Features

Conical wine fermentation tanks are widely used in the pre-fermentation of red wine, white wine, rosé wine and sparkling wine.

The fermentation tank is equipped with cooling and heating jackets. According to different process requirements, it can realize automatic temperature control (heating and cooling) during enzymatic hydrolysis, clarification, cold immersion, hot immersion alcohol fermentation and apple-milk fermentation. It can be equipped with Maitreya plate, coil jacket and insulation according to user requirements.

All our products are designed with customer process requirements as the center to meet user requirements to the maximum extent.

FAQ

Q1: What are the advantages of conical fermentation tanks compared to traditional tanks?

A: The conical bottom design facilitates the automatic settling of yeast and lees, reducing the need for manual cleaning; the stainless steel material is corrosion-resistant and provides precise temperature control; integrated fermentation and aging reduce the risk of oxidation.

Q2: Are conical fermentation tanks suitable for fermenting all types of wine?

A: Conical tanks are widely applicable for red wine (facilitating cap pressing and skin separation) and most white wines (low-temperature fermentation, easy clarification).
but they are not essential for certain specialized processes (such as the secondary fermentation of traditional method sparkling wine or wines requiring oak barrel flavor).

Q3: How should the capacity of a conical fermentation tank be selected?

A: Small wineries/experimental brewing: 500–2,000 liters; commercial production: 5,000–20,000 liters. It is recommended to reserve an additional 20% capacity based on average daily production.

Q4: Does fermentation in a conical tank affect the flavor of wine?

A: Stainless steel tanks are neutral containers that preserve the original fruit aromas of grapes.

Q5: How should conical fermentation tanks be cleaned?

A: Use food-grade acid and alkali solutions to circulate and clean it, paying particular attention to cleaning the conical bottom valve and welds. Perform deep disinfection at least once a month.
